Grinding Robot Automation Integration For 3C Or Home Appliances Processing

Place of Origin China
Brand Name CLX
Certification N/A
Model Number CLX-JM612
Minimum Order Quantity 1
Packaging Details Export Standard Plywood case pack, 1pcs/carton
Delivery Time 30 days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 50 sets/montly

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571


If you have any concern, we provide 24-hour online help.

Product Details
Industrial Robot Model CLX-JM612 Application Special Used For Grinding On Hardware
Degree Of Freedom 6 Specified Load 12KG
Maximum Working Radius 1405mm Repeatability ±0.06mm
Working Temperature 0~40° Humidity 20%~80%
Working Surrounding Avoid Contact With Flammable, Explosive Or Corrosive Gases And Liquids. Keep Away From Electronic Noise Sources (plasma). Cable Length Of Instructor 8meter
Body-cabinet Connection Length 3meter I/O Parameters Digital Quantity: 32 Input, 31 Output
Battery Capacity 3.8kVA Rated Power 3kW
Rated Voltage AC 380V/50Hz, 3 Phase Rated Current 5.4A
Body Protection Grade IP54 /IP 65(Wrist) Installation Method Ground Installation, Side Mount Installation,
Body Weight 217kg Control Cabinet Protection Grade IP53
Control Cabinet Size 650 (wide)x 580 (thick)x 940 (high) Control Cabinet Weight 100KG
High Light

Grinding Robot Automation Integration


Home Appliances Processing Industrial Grinding Robot


3C Grinding Robot Automation

Leave a Message
Product Description

High Protection And User Friendly Design Grinding Robot Automation For 3C Or Home Appliances Processing And Production

Product Description:

Robotic Automation Integration - Product Overview

Robotic Automation Integration is a cutting-edge solution for businesses that rely on Industrial Automation Machinery and Equipment. It seamlessly integrates with existing systems, ensuring high accuracy and consistency, while maintaining a detailed audit trail for compliance purposes.


"At present, the universal robots in the 3C grinding industry are difficult to adapt to the harsh working conditions such as repeated impact loads in the grinding process, dusty working environment (dry hit) and high humidity (water hit). So in order to provide customers a sustainable and stable production capacity and create higher return, we have created the CLX-JM612 which is specifically optimized for the grinding process, which also will bring you a perfect 3C grinding solution.




Key Features:
  • Audit Trail: Our product maintains a detailed audit trail for compliance purposes, ensuring that all actions performed by the system are recorded and can be traced back if needed.
  • Integration: Robotic Automation Integration seamlessly integrates with existing systems, allowing for a smooth transition without disrupting current processes.
  • Security: Data security and compliance are of utmost importance to us. Our product ensures that all data is protected and compliant with industry standards.
  • Accuracy: Our solution guarantees high accuracy and consistency in all processes, eliminating human error and improving overall efficiency.
  • 24/7 Availability: Robotic Automation Integration is available to run 24/7 without interruption. This allows for continuous operation and maximizes productivity



Why Choose Robotic Automation Integration:

1.High protection: In order to solve the problem with dust and liquid splashing during grinding, the robot arm and wrist protection level reaches IP65 as to prevent damage to the robot body caused by intruding objects.
2.Enhanced load design: In order to cope with the repeated impact of the grinding force on the robot during the grinding process, we have enhanced the design of the larger key parts of facing the impact of the robot to ensure the service life.
3.High stiffness: After enhancing the design of the forearm, the forearm can provide sufficient stiffness to cope with the impact from grinding as well as can ensure the accuracy of the trajectory and the retention of the grinding precision during the grinding process, thus, providing a long-lasting high quality grinding process.
4. High precision: absolute positioning accuracy reaches ±0.4mm, repeat positioning accuracy is ±0.06mm, which reduces the error of offline programming and actual grinding track, shortens production debugging cycle and reduces debugging difficulty.
5.Fully space utilization: Due to the needs of grinding workpiece size and process requirements, we have optimize the robot arm span specifically for 3C which can reduce the occupied area, improve the space utilization rate and increase the layout density under most of the workpiece grinding process.



Robotic Automation Integration by CLX

CLX is proud to introduce our latest product - Robotic Automation Integration. This revolutionary system combines industrial robot technology with advanced automation equipment and machinery, providing a seamless and efficient solution for various industries.

Product Attributes
Industrial robot CLX-JM612
Degree of freedom 6
Specificed load 12Kg
Maximum working radius 1405mm
Repeatability ±0.06mm
Range of motion J1 ±168°
J2 -170°/+75°
J3 +40°/+265°
J4 ±180°
J5 ±125°
J6 ±360°
Rated speed J1 2.58 rad/s,148°/s
J2 2.58 rad/s,148°/s
J3 2.58 rad/s,148°/s
J4 6.28rad/s,360°/s
J5 3.93rad/s,225°/s
J6 6.28rad/s,360°/s
Maximum speed J1 3.44rad/s,197.33°/s
J2 3.44rad/s,197.33°/s
J3 3.44rad/s,197.33°/s
J4 10.47rad/s,600°/s
J5 6.54rad/s,375°/s
J6 10.47rad/s,600°/s
Allowable moment of inertia J6 0.17kg㎡
J5 1.2kg㎡
J4 1.2kg㎡
Allowable torque J6 15Nm
J5 35Nm
J4 35Nm
Applicable environment temperature 0~40°
humidity 20%~80%
other Avoid contact with flammable, explosive or corrosive gases and liquids. Keep away from electronic noise sources (plasma).
Cable Length of Instructor 8metre
Body-cabinet connection length 3metre
I/Oparameters Digital Quantity: 32 Input, 31 Output
battery capacity 3.8kVA
rated power 3kW
Rated voltage AC 380V/50Hz, 3 Phase
Rated current 5.4A
Body protection grade IP54 /IP 65(Wrist)
Installation method Ground Installation, Side mount Installation,
Body weight 217kg
Control cabinet protection grade IP53
Control cabinet size 650 (wide)x 580 (thick)x 940 (high)
Control cabinet weight 100KG
  • Brand Name: CLX
  • Model Number: N/A
  • Place of Origin: China
  • Cost-Effective: Our Robotic Automation Integration system saves time and resources, leading to cost savings for businesses. By automating repetitive tasks, companies can reduce labor costs and increase productivity.
  • 24/7 Availability: Our system is designed to run 24/7 without any interruptions, providing round-the-clock support for your operations.
  • Compatibility: Our system is compatible with various systems and applications, making it easy to integrate into your existing processes.
  • Real-Time Monitoring: With real-time monitoring and reporting, our system provides instant updates on the status of your operations, allowing for timely decision making and problem-solving.
  • Intelligence: Our system utilizes artificial intelligence (AI) and machine learning to analyze data and make intelligent decisions, leading to improved efficiency and accuracy in your operations.
Application Scenarios
Industrial Robot System Integration

Our Robotic Automation Integration system can be integrated with existing industrial robot systems, enhancing their capabilities and increasing efficiency. By automating tasks such as material handling, assembly, and packaging, our system can improve production speed and reduce errors.

Industrial Automation Equipment Integration

Our system can also be integrated with various industrial automation equipment, such as conveyors, sensors, and controllers. This allows for a seamless flow of data and communication between different equipment, optimizing the entire production process.

Industrial Automation Machinery Integration

Our system is compatible with a wide range of industrial automation machinery, including CNC machines, 3D printers, and packaging machines. By automating these machines, companies can achieve higher accuracy, faster production, and reduced downtime.

Why Choose CLX's Robotic Automation Integration?
  • Our system is cost-effective, saving businesses time and resources.
  • It is available 24/7, providing round-the-clock support for operations.
  • Our system is compatible with various systems and applications, making it easy to integrate into existing processes.
  • It provides real-time monitoring and reporting for timely decision making.
  • Our system uses AI and machine learning for intelligent decision making.

With CLX's Robotic Automation Integration, businesses can achieve higher efficiency, lower costs, and improved productivity. Upgrade your operations today and experience the benefits of our cutting-edge technology.



Robotic Automation Integration Customization Service

Brand Name: CLX

Model Number: N/A

Place of Origin: China

Audit Trail: Maintains A Detailed Audit Trail For Compliance Purposes

Compatibility: Works With Various Systems And Applications

User-Friendly: Easy To Use And Requires Minimal Training

Integration: Seamlessly Integrates With Existing Systems

Cost-Effective: Saves Time And Resources, Leading To Cost Savings

At CLX, we understand the importance of customization in the industrial robot system and industrial automation machinery industry. That's why we offer a comprehensive Robotic Automation Integration Customization Service to meet the specific needs of our clients.

Our service is designed to seamlessly integrate with existing systems, ensuring a smooth and efficient process. With our expertise in automation and robotics, we guarantee compatibility with various systems and applications.

Our Audit Trail feature maintains a detailed record of all activities, providing compliance and regulatory purposes. This ensures transparency and accountability in your operations.

Our user-friendly interface makes it easy to use our customization service, requiring minimal training for your team. This saves time and resources, leading to cost savings in the long run.

With our Robotic Automation Integration Customization Service, you can enhance the performance of your industrial robot system and industrial automation machinery, maximizing productivity and efficiency. Trust CLX for all your automation needs.


Packing and Shipping:

Packaging and Shipping for Robotic Automation Integration

To ensure the safe and efficient delivery of our Robotic Automation Integration product, we have implemented a comprehensive packaging and shipping process. This process includes the following steps:


Our packaging team carefully inspects each component of the Robotic Automation Integration product before packaging to ensure quality control. The product is then securely packaged with protective materials to prevent any damage during transportation.

We also use environmentally friendly packaging materials whenever possible to minimize our impact on the environment.


We offer various shipping options to accommodate our customers' needs, including standard ground shipping, express shipping, and international shipping. Our team works closely with reputable shipping carriers to ensure timely and reliable delivery of our product.

For international shipping, we handle all necessary customs and documentation requirements to ensure a smooth delivery process.

Upon shipment, customers will receive a tracking number to monitor the status of their order. We also offer expedited shipping options for urgent orders.

At Robotic Automation Integration, we are committed to providing a seamless packaging and shipping experience for our customers. If you have any questions or concerns, please don't hesitate to contact our customer service team.



  • Q: What is the brand name of this product?
    A: The brand name of this product is CLX.
  • Q: Does this product have a model number?
    A: No, this product does not have a specific model number as it is a software solution.
  • Q: Where is this product manufactured?
    A: This product is manufactured in China.
  • Q: What is the main function of Robotic Automation Integration?
    A: The main function of Robotic Automation Integration is to automate repetitive tasks and streamline business processes.
  • Q: Can this product be customized for specific business needs?
    A: Yes, Robotic Automation Integration can be customized to fit the specific needs of a business.
